WPFA- K4C Clip-on Hydraulic Hinge Fix-on Hydraulic Hinge soft close clip on doors concealed hinge furniture

Classic Style

Strong Bearing With 1.2mm Materials

K4 Series
Commodity:	K4 Series Clip-on Hydraulic Hinge
Item No.:	K4-012A/B4-0T(full overlay) K4-012B/B4-0T(half overlay) K4-012C/B4-0T(inset) K4-022A/B4-0T(full overlay) K4-022B/B4-0T(half overlay) K4-022C/B4-0T(inset)
Material:	Cold roolled steel
Finish:	Nickel Plated
Type:	Clip-on
Diameter of hinge cup:	35mm
Depth of hinge cup:	11.5mm
Panel Size:	3-7mm
Door thickness:	15-24mm
Door adjustable:	3-dimensional
Cover adjustment:	0-4mm
Depth adjustment:	-3mm/+3mm
Base adjustment:	-2.5mm/+2.5mm
Opening angle:	100°±5°
Thickness of cup:	0.7mm
Thickness of arm:	1.2mm
Product function:	Soft close
Product type:	Two way/One Way
Optional accessories:	Cup cap; arm cap; screws
Optional plate:	4-holes plate
Cycle test:	60 000 times
Salt spray test:	48 hours/Grade 9
MOQ:	20 000 pcs
OEM:	More than 20 000 pcs can be OEM
Packing:	2 pcs/polybag, 100 pcs/ctn (can pack as customers’ requirements)
QTY:	180 000 pcs/ctr
Supply ability:	6 000 000 pcs/month
Delivery time:	Normally within 30 days after receiving deposit
Payment:	30%deposit, 70% against BL copy.
Sample offer:	Less than 30 pcs as free samples, but express charge will be beared by buyer.
Sample arrangement:	Samples will be prepared to sending in about 3 working days.
Sample delivery:	DHL/UPS/Fedex/TNT: 3-5 days; EMS: 7 days
